You can also check the pressure of the O2 cell and CO2 sensor.
Remove all tubes from the Ergostiks (front and back)
Gas Valve Open / Cal Gas Valve Closed | Range |
CO2 Cell Pressure | 20-40 below ambient pressure |
O2 Cell Pressure | 70-90 below ambient pressure |
Gas Valve Closed / Cal gas Valve Closed | Range |
CO2 Cell Pressure | 50-70 below ambient pressure |
O2 Cell Pressure | 100-120 below ambient pressure |
Set the pump speed to 0
CO2 Cell Pressure | ambient pressure +/- 10 |
O2 Cell Pressure | ambient pressure +/- 10 |
